| Overall Height | 71.1 |
| ABS Sensor Ring Included | No |
| Discard Thickness | 18.4 |
| Wheel Bolt Circle Diameter | 4.724 |
| Heavy Duty Supplier | Yes |
| Brake Rotor Diameter, Outer | 12.992 |
| Wheel Bolt Hole Diameter, Maximum | 0.665 |
| Inside Diameter | 216.6 |
| Wheel Bolt Hole Diameter, Minimum | 0.645 |
| Wheel Bolt Holes, Primary | 5 |
| Brake Rotor Type | Conventional |
| Salability Restrictions | No |
| Height | 71.100 |
| Mounting Bolt Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
| Harmonize Code | 8708.30.5030 |
| Height, Overall | 2.799 |
| Rotor Braking Surface Machining Type | Uniform |
| Solid Or Vented Type Rotor | Vented |
| Center Hole Diameter, Maximum | 2.958 |
| Brake Rotor Thickness, Nominal | 0.787 |
| Brake Rotor Casting Type | Vented |
| Brake Rotor Thickness, Discard | 0.724 |
| Performance Level | Standard Performance |
| Brake Rotor Diameter, Inner | 8.528 |
| Surface Type | Smooth |
| Outside Diameter | 330 |
| Nominal Thickness | 20 |
| Center Hole Diameter, Minimum | 2.953 |
| Part Terminology | Disc Brake Rotor |
